Máquina de llenado de tambor
No matter from which product line you choose your filling machine: VKPAK makes no difference in quality referring to filling valves, filling accuracy and filling speed. The same components are used in all lines.
VKPAK has various machine designs for drum filling, tote filling, and liquid filling of other palletized bulk sizes e.g. 25 gallon barrels, etc. These drum filling systems are available in chemical duty construction and food grade construction in either top fill only or bottom up fill (subsurface) configurations. Top drum filling configurations are less expensive but limited to non foaming bulk products. Bottom up drum filling configurations are very flexible systems capable of filling almost any bulk product within a wide range of foamy characteristics and viscosities.
ACERCA DE LLENADORES DE TAMBOR:
Los sistemas de llenado de tambor de llenado superior e inferior utilizan una escala integrada y un transportador de rodillos de paletas motorizado. El sistema funciona con una mínima participación del operador. El operador coloca el palé, la bolsa o los tambores en la plataforma de la báscula con un interruptor de control del transportador. Luego, el operador utiliza el interruptor del brazo de equilibrio de la boquilla para la colocación manual (peso cero) en la apertura del tambor, el barril o la bolsa. Luego, el operador activa el llenado automático y la boquilla se abre y la bomba se llena hasta el peso.
Drum filler systems can be supplied with VKPAK supplied custom pump systems or fed by customer’s existing bulk supply system.This system eliminates the physical effort normally associated with 55-gallon drum handling.Remote stainless steel NEMA 4x washdown capable PLC control panel is connected to the drum and tote filler by waterproof cable and allows operator access and control away from immediate filling area.
